Wireless IP camera from China manufacturer - CHUANGLONG TECHNOLOGY(HK)SHARE CO.,LIMITED

Payment Terms:	T/T,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: CLG-530W

Packing: standard export packing

Brand Name: KAVASS

Sensor: CMOS

Compress format: M-JPEG

Pan Coverage/Tilt Coverage: 350°/100°

Motion detection: Alarm function

Means of Transport: Express Courier like UPS DH...

Delivery Date: 3-5days

Type: IP camera

Lens: 4mm Fixed Iris

Infrared LED 36 pcs: 30m infrared distance

H.264 Wireless IP camera: Visit through web browser o...

H.264 Wireless IP camera
Infrared day and night, pan tilt
Dual way audio, 4 zone motion detection
free DDNS
phone view

H.264/M-JPEG IR Cut Pan Tilt Wireless IP camera

Detailed Specification

Package Includes

1) Wireless IP camera

2) 1.5m cable

3) CD Driver (Software and Manual)

4) Bracket

5) Adaptor

Item	Sub item	Description
Image Capture	Sensor	1/4" CMOS sensor
	Total of pixel	300k
	Minimum illumination	IR lights on,0 Lux
	Lens	f=4.0mm, F=2.0, Fixed Iris
	IR_CUT	Support IR and color filter change automatically
Pan/Tilt	Pan Coverage	350°
	Tilt Coverage	100°
	Preset Numbers	1
Assistant	Lighting Control	Auto/manual control
Assistant	Lighting	8pcs 850nm Infrared lights, 5m distant
Video and Audio	First Stream Resolution	VGA/QVGA/QQVGA
	Second Stream Resolution	QVGA/QQVGA
	Compression	H.264/JPEG
	Frame rate	30fps
	First Stream Bit rate	90kbps ~ 2.048Mbps
	Second Stream Bit rate	90kbps ~ 512kbps
	Image Rotation	Flip / Mirror
	OSD	support
	Audio Compression	G.711/G.726
Network	Basic Protocol	TCP/IP,HTTP,SMTP,FTP,DHCP,DDNS,UPNP,NTP
Network	Other Protocol	802.11b/g/n
Other Features	Mobile Phone View	support
	Video control	support
	Dual way audio	support
	Memory	Snap or video into SD card
	Browser SD card	View or download from network
	Motion Detection	yes( 4 zone detection )
	Triggered Actions	Email/FTP/SD storage/external alarm/send message to alarm server
	User Setting	Three levels
	Date/ Time Setting	support
	Upgrade	Upgrade from network
	DDNS	A free DDNS provided by manufacturer
Hardware Interface	Ethernet	10Base-T/100base-TX
	Memory	SD Slot
	Alarm In	1 way
	Alarm Out	1 way
	Audio In	Internal mic x 1, audio input interface x 1
	Audio Out	audio output interface x 1
Physical Index	Weight	358g
	Main body	111mm(L)107mm(W)121mm(H)
	Power	DC 5V
	Power consumption	<6W
	Operating temperature	-20°C~ 50°C
	Humidity	10% ~ 80% non-condensing
Software(PC Side)	OS Supported	Microsoft Windows 98/2000/XP/Vista etc.
	Browser	Internet Explorer6.0 and Above or Compatible Browser, Safari/Firefox etc.
	Application Software	IPCMonitor.exe
